Cover release
latch
Top cover
3. Slide the cover toward the front of the server; then, press down on the cover
release latch until it clicks into place.
4. Slide the server back into the rack cabinet until it latches.
5. Reconnect the external cables and power cords.
Removing the bezel
This information provides instructions on how to remove the bezel.
About this task
To remove the bezel, complete the following steps:
Procedure
1. Read the safety information and installation guidelines, see “Safety” on page vii
and “Installation guidelines” on page 35.
2. Turn off the server (see “Turning off the server” on page 22) and all attached
peripheral devices. Disconnect all power cords; then, disconnect all external
cables as necessary to replace the device.
3. Slide the server out of the rack.
4. Remove the screws from the bezel with a Torx screwdriver.
228 System x3750 M4 Types 8722 and 8733: Installation and Service Guide
