IBM System x3750 M4

Removing a USB embedded hypervisor flash device
This information provides instructions on how to remove a USB embedded
hypervisor flash device.
About this task
To remove a USB embedded hypervisor flash device, complete the following steps:
Procedure
1. Read the safety information and installation guidelines, see “Safety” on page vii
and “Installation guidelines” on page 35.
2. Turn off the server (see “Turning off the server” on page 22) and all attached
peripheral devices. Disconnect all power cords; then, disconnect all external
cables as necessary to replace the device.
3. Remove the top cover (see “Removing the server top cover” on page 226).
4. If any adapters are installed in the PCI riser-card assembly, disconnect any
cables that are connected to the adapters.
5. Remove the PCIe riser-card assembly (see “Removing a PCI riser-card
assembly” on page 283).
6. Locate the USB embedded hypervisor flash device connector on the system
board.
7. Slide the lockbar on the USB flash device connector down to the unlocked
position and pull the USB flash device out of the connector.
Lockbar
USB Hypervisor key
8. If you are instructed to return the flash device, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
