Supported adapters
This information describes the adapters that server supports and the sequence for
installing the adapters in the server.
About this task
The following table lists the adapters that the server supports:
Table 17. Supported adapters, slot in which to install the adapters, and information about the adapters.
Name of adapter
Suggested slot
installation sequence Notes
ServeRAID M5110
SAS/SATA Controller for
IBM System x
PCIe slots 1, 2, and 3
v Provides base RAID levels 0, 1, and 10:
– With the ServeRAID M5100 Series Zero Cache/RAID 5
Upgrade for IBM System x (Features On Demand
software RAID) enabled on this adapter, you also get
RAID levels 5 and 50 support.
v You can also install the following RAID cache cards on this
adapter to get RAID levels 5 and 50 support:
– ServeRAID M5100 Series 512 MB Cache/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 512 MB Flash/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 1 GB Flash/RAID 5 Upgrade for
IBM System x
Note: When any of these three cache cards is installed on
this adapter, you can enable the ServeRAID M5100 Series
RAID 6 Upgrade for IBM System x (Features On Demand
software RAID) to get RAID levels 6 and 60 support.
Optionally, the ServeRAID M5100 Series SSD Caching
Enabler for IBM System x (Features On Demand software
RAID) can be enabled to accelerate solid-state drive RAID
devices and reduce processing overhead associated with
caching or the ServeRAID M5100 Series Performance
Accelerator for IBM System x (Features On Demand software
RAID) can be enabled to allow HDD RAID array to have its
own SSD cache.
v A RAID cache card must be installed on this adapter to run
the MegaRAID firmware.
72 System x3750 M4 Types 8722 and 8733: Installation and Service Guide
