Table 17. Supported adapters, slot in which to install the adapters, and information about the adapters. (continued)
Name of adapter
Suggested slot
installation sequence Notes
ServeRAID M1115
SAS/SATA Controller for
IBM System x
PCIe slots 1, 2, and 3
v Provides base RAID levels 0, 1, and 10:
– With the ServeRAID M1100 Series Zero Cache/RAID 5
Upgrade for IBM System x (Features On Demand
software RAID) enabled on this adapter, you also get
RAID level 5 and 50 support.
– Optionally, the ServeRAID M5100 Series SSD Caching
Enabler for IBM System x (Features On Demand software
RAID) can be enabled on this adapter to accelerate
solid-state drive RAID devices and reduce processing
overhead that is associated with caching.
v Does not support the following RAID cache cards:
– ServeRAID M5100 Series 512 MB Cache/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 512 MB Flash/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 1 GB Flash/RAID 5 Upgrade for
IBM System x
ServeRAID M5120
SAS/SATA Controller for
IBM System x
PCIe slots 1, 2, 3, 4,
5, 6, 7, and 8
v Provides base RAID levels 0, 1, 5, 10, and 50 (This adapter
comes with a cache card installed):
– With the ServeRAID M5100 Series RAID 6 Upgrade for
IBM System x (Features On Demand software RAID)
enabled on this adapter, you also get RAID level 6 and 60
support.
v You can also install the following RAID cache cards on this
adapter for RAID levels 5 and 50 support:
– ServeRAID M5100 Series 512 MB Cache/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 512 MB Flash/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 1 GB Flash/RAID 5 Upgrade for
IBM System x
Note: When any of these three cache cards is installed on
this adapter, you can enable the ServeRAID M5100 Series
RAID 6 Upgrade for IBM System x (Features On Demand
software RAID) to get RAID levels 6 and 60 support.
Optionally, the ServeRAID M5100 Series SSD Caching
Enabler for IBM System x (Features On Demand software
RAID) can be enabled on this adapter to accelerate
solid-state drive RAID devices and reduce processing
overhead that is associated with caching.
v A RAID cache card must be installed on this adapter to run
the MegaRAID firmware.
v The adapter supports external cabling.
v The battery must always be mounted remotely in the server.
IBM 6Gb Performance
Optimized Host Bus
Adapter
PCIe slots 1, 2, and 3
v This solid-state drive controller provides no RAID support.
It helps provide optimized performance for applications that
do not need RAID support.
Chapter 2. Installing optional devices 73
