Backplane configurations for 20 drives
This information describes the supported backplane configurations for 20 drives.
About this task
The following illustrations show the supported drive backplane configurations to
support 20 drives.
This configuration consists of three 4x2.5-inch drive backplanes and one
8x1.8-inch drive backplane and requires five SAS signal cables.
8 9 10 11
0123 4567
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
24 272625 28 29
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
30 31
This configuration consists of one 8x2.5-inch drive backplane, one 4x2.5-inch
drive backplane, and one 8x1.8-inch drive backplane and requires five SAS
signal cables.
8 9 10 11
01234567
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
24 272625 28 29
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
30 31
This configuration consists of one 4x2.5-inch drive backplane and two
8x1.8-inch drive backplanes and requires five SAS signal cables.
2.5” HDD/SSD
0123
Empty
2.5” HDD/SSD
2.5” HDD/SSD
2.5” HDD/SSD
16 191817 20 21
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
22 23
8 9 10 15
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1.8” SSD
1112 13 14
62 System x3750 M4 Types 8722 and 8733: Installation and Service Guide
