Replacing a memory module
This information provides instructions on how to replace a memory module.
About this task
The following illustration shows the location of the DIMM connectors on the
system board.
DIMM 1
DIMM 2
DIMM 3
DIMM 4
DIMM 5
DIMM 6
DIMM 24
DIMM 23
DIMM 22
DIMM 21
DIMM 20
DIMM 19
DIMM 7
DIMM 8
DIMM 9 DIMM 11
DIMM 10
DIMM 18
DIMM 17
DIMM 16DIMM 14
DIMM 15DIMM 12 DIMM 13
The following illustration shows the location of the DIMMs on the optional
microprocessor and memory expansion tray:
Tray handle
Memory tray
DIMMs
25-30
DIMMs
31-42
DIMMs
43-48
Microprocessor 3
Microprocessor 4
Tray handle
Power supply 2
connector
Note:
Chapter 6. Removing and replacing components 247
