Replacing the fan cage assembly
This information provides instructions on how to replace the fan cage assembly.
About this task
To replace the fan cage assembly, complete the following steps:
Procedure
1. Align the tabs on the fan cage assembly with the slots on both sides of the
chassis and lower it into the server.
Release
latch
Release
latch
Fan cage
assembly
Slots
Slots
2. Rotate the fan cage assembly release latches down until the release latches are
in the locked position.
3. Reinstall the cover (see “Replacing the server top cover” on page 227).
4. Slide the server into the rack.
5. Reconnect the power cord and any cables that you removed.
6. Turn on the peripheral devices and the server.
Chapter 6. Removing and replacing components 271
