v The server provides one PCIe riser-card slot on the system board. The riser-card
provides three PCI Express Gen3 adapter slots (see “PCIe riser card” on page 35
for the location of the PCIe slots on the riser card). The system board provides
five additional PCI Express Gen3 adapter slots (see “System-board
optional-device connectors” on page 33 for the location of the PCIe slots on the
system board). Some models come with the PCIe riser-card assembly with
brackets installed. The following table lists the PCIe slots on the riser-card and
the system board, the microprocessor to which each slot is connected, and the
supported adapters that you can install in each slot.
Table 16. PCIe slots, the microprocessor which supports the PCIe slot, and the size of the PCIe adapters supported
PCIe slots
Slot on PCI riser
card
Slot on the system
board
Microprocessor to
which the slot is
connected
Adapters supported
in the slot
Slot 1 Yes Microprocessor 2 PCIe Gen3 x16 (x8,
x4, x2, x1) full-height,
half-length adapter
Slot 2 Yes Microprocessor 2 PCIe Gen3 x16 (x8,
x4, x2, x1) full-height,
half-length adapter
Slot 3 Yes Microprocessor 2 PCIe Gen3 x16 (x8,
x4, x2, x1) full-height,
half-length adapter
Slot 4 Yes Microprocessor 2 PCIe Gen3 x8
low-profile adapter
Slot 5 Yes Microprocessor 2 PCIe Gen3 x8
low-profile adapter
Slot 6 Yes Microprocessor 1 PCIe Gen3 x8
low-profile adapter
Slot 7 Yes Microprocessor 1 PCIe Gen3 x8
low-profile adapter
Slot 8 Yes Microprocessor 1 PCIe Gen3 x8
low-profile adapter
Note:
v The x16 (x8) designation for a PCIe slot identifies a x16 slot that is wired for x8. If you install a x16 adapter in
this slot that can downshift to the x8 bandwidth, it will run at the x8 bandwidth. The x16 connector can be used
for x8, x4, x2, x1, and x16 adapters. Check the information that comes with your adapter for compatibility
information.
v The server also supports PCIe Gen1 and Gen2 adapters.
v The server comes with an onboard RAID controller that provides basic RAID
levels 0, 1, and 10 functionality. The server supports optional RAID controllers,
RAID cache cards, and Feature On Demand software RAID that you can
purchase for additional RAID levels 5, 6, 50, and 60 support. For configuration
information, see the documentation that comes with the adapter or the
ServeRAID documentation at http://www.ibm.com/supportportal/.
For more information about the supported adapters, see Table 17 on page 72. For
more information about the supported RAID cache cards, see Table 18 on page
74. For more information about the supported Features on Demand (FoD)
software, see Table 19 on page 75. For instructions on how to install an adapter,
see “Adapter installation instructions” on page 76.
Chapter 2. Installing optional devices 71
