5-22 How to Set the External Outputs
Rev AA
ICE Vulcan Service Manual
Options
Machine is Online
Machine Leaves Fault
Machine Leaves Warning
Machine Starts Printing
New Job Allocation Received
New Job Allocation Rendered
Not Used
Print Data is Not Ready
Print Data is Ready
Print Failed
Print Signal Ignored
Reject Product
Table 5-2: External Output 1-3 Options (Continued)
Status of the Warning Beacon in Typical Setup
The external outputs 1-3 are evaluated with reference to the status of the warning beacon
(see Figure 5-14).
CLARiTY is Offline CLARiTY is Online CLARiTY enters warning
CLARiTY Fault
Figure 5-14: Various Indications of the Warning Beacon in Typical Setup
