SET MODE ITEMS
ITEMS DESCRIPTIONS RANGE OR VALUE REF.
CW Normal Side Carrier point setting for the CW mode op-
eration.
LSB, USB p. 15-16
APF Type Audio filter shape setting for APF. SOFT, SHARP
MIC AF Out Band selection for audio output from [MIC]
(pin 8).
MAIN+SUB, SUB
MIC Input DC Bias Bias voltage setting for modulation input line
([MIC] pin 1).
OFF, ON
External Keypad (VOICE)
[EXT KEYPAD] (rear
panel), or [MIC] (front
panel)
Voice memory trans-
mission setting for
an external keypad.
OFF, ON
External Keypad (KEYER) Memory keyer trans-
mission setting for
an external keypad.
External Keypad (RTTY) RTTY memory trans-
mission setting for
an external keypad.
External Keypad (PSK) PSK memory trans-
mission setting for
an external keypad.
Keyboard [F1]–[F8] (VOICE) [USB A] (rear panel) Voice memory trans-
mission for the con-
nected keyboard
([F1]~[F8] keys).
OFF, ON
Keyboard [F1]–[F8] (KEYER) Memory keyer trans-
mission for the con-
nected keyboard
([F1]~[F8] keys).
Screen Capture [POWER] SW Screen capture function setting for the
[POWER] switch operation.
OFF, ON p. 15-17
Screen Capture Keyboard [Print
Screen]
Screen capture function setting for the [Print
Screen] key on the connected keyboard.
Screen Capture Storage Media Storage media setting for the captured
screen image file to save.
SD CARD, USB-Memory
Screen Capture Data Format Saving file format setting for the captured
screen image file.
PNG, BMP
Shutdown Function Shutdown option selection for the remote
power control.
Shutdown,
Standby/Shutdown
CI-V Baud Rate CI-V data transfer speed setting. 4800, 9600, 19200 (bps), Auto
CI-V Address Transceiver's address setting for the CI-V
remote control.
02h~8Eh~DFh
CI-V Transceive Transceive function setting for the CI-V re-
mote control.
OFF, ON
CI-V USB/LANREMOTE Trans-
ceive Address
CI-V address setting for the 2nd transceiv-
er or receiver controlled by the transceive
function.
00h~DFh
CI-V Output (for ANT) Antenna controller Status data output set-
ting.
OFF, ON p. 15-18
OTHERS SET(Continued) 
