Icom IC-R30 User Manual

7
OTHER FUNCTIONS
7-7
■ Descrambler function
<MODE> dPMR
You can descramble the scrambled dPMR (Tire2 Mode1/Mode2) communication by
entering the appropriate key.
• Selectable keys: 1 ~ 32767
1. Push [QUICK].
2. Select “SCRAM.”
(Rotate [DIAL] to select it, then push [ENTER].)
3. Select “ON (1).”
4. Select the key.
L “SCRM” is displayed on the right side of the screen.
■ Decryption function
<MODE> NXDN-vn, NXDN-n and DCR
You can decrypt the encrypted NXDN or DCR communication by entering the
appropriate key.
• Selectable keys: 1 ~ 32767
1. Push [QUICK].
2. Select “ENCR.”
(Rotate [DIAL] to select it, then push [ENTER].)
3. Select “ON (1).”
4. Select the key.
L “ENCR” is displayed on the right side of the screen.

Icom IC-R30 Specifications

General

Antenna Connector	SMA
GPS	Yes
Modes	AM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power	5V DC (USB), or 7.4V DC (battery)
Battery Life	Approx. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
Bluetooth	Yes
