Icom IC-R30 User Manual

2
microSD Card
2-9
■ Importing or Exporting a CSV format le
You can importing or exporting a Comma Separated Values (CSV) format le to or from
the microSD card. You can separately import or export the following data:
• Memory channels
• Programmable Scan Edges
• GPS Memories
NOTE: The receiver cannot display a le that has a le name longer than 10
characters. In this case, rename it using 10 characters or less.
When you export the data in a CSV format le using the CS-R30 (option), make sure to
name it using 10 characters or less.
TIP: CSV is a le format that is used to read or write the IC-R30’s setting data.
You can import the setting data to a PC, and edit it using the CS-R30.

Icom IC-R30 Specifications

General

Antenna Connector	SMA
GPS	Yes
Modes	AM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power	5V DC (USB), or 7.4V DC (battery)
Battery Life	Approx. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
Bluetooth	Yes
