2
microSD Card
2-10
Importing or Exporting a CSV format le
D Importing
TIP: Before importing, make a backup le of all the receiver’s data to the microSD card
in case of data loss.
Example: Importing memory channels.
[MENU] > SD Card > Import/Export > Import
1. Push [MENU].
2. Select “Import” in the “SD Card” menu.
(Rotate [DIAL] to select it, then push [ENTER].)
3. Select “Memory CH,” and then push [ENTER].
4. Select the Memory group that contains the memory channel to import, then push
[ENTER]. (Example: Group 03)
NOTE: If you select “ALL,” all the memory channels except in the Auto Memory
Write channel group (A:Auto MW CH) and Skip channel group (S:SKIP CH) are
deleted, before importing.
5. Select the CSV file to import.
A conrmation dialog is displayed.
6. Select “YES,” and then push [ENTER].
Starts to import.
L After importing ends, “COMPLETED! Restart the IC-R30.” is displayed.
7. Restart the IC-R30 to complete the importing.

Table of Contents

Other manuals for Icom IC-R30

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Icom IC-R30 and is the answer not in the manual?

Icom IC-R30 Specifications

General IconGeneral
Antenna ConnectorSMA
GPSYes
ModesAM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power5V DC (USB), or 7.4V DC (battery)
Battery LifeApprox. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
BluetoothYes
