2
microSD Card
2-4
Loading the saved data from the microSD card
The saved memory channels, item settings on the menu screen can be copied to
another IC-R30. This function is convenient when sharing data with other IC-R30s.
L Saving the current data on to a microSD card is recommended before loading the data.
Example: Loading setting data “Set20180216_01”
[MENU] > SD Card > Load Setting
1. Push [MENU].
2. Select “Load Setting” in the “SD Card” menu.
(Rotate [DIAL] to select it, then push [ENTER].)
3. Select the desired file to be loaded, then push [ENTER].
A conrmation dialog is displayed.
4. Select “YES,” and then push [ENTER].
Starts the le check. After checking, starts settings data loading.
After loading, “COMPLETED! Restart the IC-R30.” is displayed.
5. Restart the IC-R30.

Table of Contents

Other manuals for Icom IC-R30

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Icom IC-R30 and is the answer not in the manual?

Icom IC-R30 Specifications

General IconGeneral
Antenna ConnectorSMA
GPSYes
ModesAM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power5V DC (USB), or 7.4V DC (battery)
Battery LifeApprox. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
BluetoothYes
