Icom IC-R30 User Manual

2
microSD Card
2-5
■ Backing up the data from a microSD card onto
a PC
A backup le restoring, even if the data on the microSD card is accidentally deleted or
corrupted.
D About the microSD card’s folder
The folders contained in the microSD card are as follows:
q IC-R30 folder
The folders created in the IC-R30 are in
this folder.
w Csv folder
Contains the GPS Memory, Memory
channels, Programmable Scan Edges
Import/Export folders.
e GpsMemory folder
Contains the GPS Memory in the “csv”
format to import or export.
r MemoryCh folder
Contains the Memory channels in the
“csv” format to import or export.
t ScanEdge folder
Contains the Programmable Scan Edges
in the “csv” format to import or export.
y Gps folder
GPS logging data is stored in the “log”
format.
u RXLog folder
RX record log data is stored in the “csv”
format.
i Setting folder
IC-R30’s setting data is stored in the “csv”
format.
o Voice folder
The recorded RX recorder audio date
folders are created in the Voice folder.
!0 yyyymmdd folder
Recorded audio le is stored in the “wav”
format.
The folder name is automatically created
in the following format:
yyyymmdd (yyyy:Year, mm:month, dd:day)
q IC-R30
w Csv e GpsMemory
r MemoryCh
t ScanEdge
!0 yyyymmdd
!0 yyyymmdd
y Gps
u RXLog
i Setting
o Voice

Icom IC-R30 Specifications

General

Antenna Connector	SMA
GPS	Yes
Modes	AM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power	5V DC (USB), or 7.4V DC (battery)
Battery Life	Approx. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
Bluetooth	Yes
