Icom IC-R30 User Manual

7
OTHER FUNCTIONS
7-28
You can clone receivers from a PC using a microSD card.
1. Connect the receiver and a PC using the supplied USB cable.
2. Turn ON the receiver power.
3. Push [MENU].
4. Select “USB Connect” in the “Function” menu.
(Rotate [DIAL] to select it, then push [ENTER].)
• A conrmation dialog appears.
5. Select “SD Card Mode.”
6. Select “YES,” and then push [ENTER].
• Displays the IC-R30 folder on the PC screen.
7. Save the setting data as an “icf” file, then put it into the “Setting” folder in the “IC-
R30” folder on the microSD card.
8. Perform the SD card removal on the PC.
9. Insert the microSD card that includes the “icf” file, then load it to complete the
cloning.
Connections
Put in the icf le
IC-R30
Gps
Setting
Voice yyyymmdd
yyyymmdd
RxLog
Csv
GpsMemory
MemoryCh
ScanEdge
■ Cloning function (Continued)
D Cloning from a PC using a microSD card
microSD card conguration
To a USB port
Supplied USB cable
IC-R30 is recognized
as a USB ash drive
CS-R30

Icom IC-R30 Specifications

General

Antenna Connector	SMA
GPS	Yes
Modes	AM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power	5V DC (USB), or 7.4V DC (battery)
Battery Life	Approx. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
Bluetooth	Yes
