Icom IC-R30 User Manual

4
MEMORY OPERATION
4-8
■ Copying Memory contents to the VFO
You can copy the Memory contents to the VFO.
Example: Copying the contents of channel 00 in group 00 to the VFO.
1. Push [VFO/MR] to select the Memory mode.
2. Rotate [DIAL] to select the channel.
• The selected Memory channel number blinks.
3. Push [MW].
4. Select “Copy to VFO.”
(Rotate [DIAL] to select it, and then push [ENTER].)
• A conrmation dialog appears.
5. Select “Yes.”
• Beeps sound and the selected memory contents are copied to the VFO, then returns to
the VFO mode screen.

Icom IC-R30 Specifications

General

Antenna Connector	SMA
GPS	Yes
Modes	AM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power	5V DC (USB), or 7.4V DC (battery)
Battery Life	Approx. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
Bluetooth	Yes
