Icom IC-R30 User Manual

vii
About the air ventilation holes
There are air ventilation holes on the receiver body and battery pack/case that adjust the
air pressure inside of the receiver.
L Applying a sticker over the ventilation hole blocks the air pressure adjustment, and may
decrease the audio output level.
L Damage to the ventilation sheet may reduce the water protection capability.
Here is an air
ventilation hole
under the sheet.
Here is an air
ventilation hole.
Here is an air
ventilation hole.
INTRODUCTION
Ventilation sheet

Icom IC-R30 Specifications

General

Antenna Connector	SMA
GPS	Yes
Modes	AM, FM, WFM, CW, D-STAR, P25, NXDN, dPMR
Power	5V DC (USB), or 7.4V DC (battery)
Battery Life	Approx. 8 hours (with external speaker), Approx. 10 hours (with internal speaker)
Bluetooth	Yes
