9
MENU SCREEN
9-56
The RX log contents are shown below:
Contents Example Descriptions
Frequency 438.010000 RX Frequency
Mode DV Operating mode (DV mode is xed)
Caller JA3YUA A Call sign of the caller station (up to 8 characters)
/ 4100 Note after the call sign (up to 4 characters)
Called CQCQCQ Call sign of the called station
Rx RPT1 JP3YHH G
Access repeater call sign of the caller station or the gateway repeater call sign
of your local area repeater.
Rx RPT2 JP3YHJ A Access repeater call sign of the called station
Message
Hello CQ D-STAR!
Message included in the received call (up to 20 characters)
Status (Blank)
Normal: blank, Uplink: “RPT UP”, Access repeater reply: “UR?” or “RPT?”
Received date 4/1/2017
13:51:48
Date and time the call was received
Depending on the setting, the format may differ.
BK * BK call:
“
*
”, Normal call: Blank
EMR * EMR call:
“
*
”, Normal call: Blank
Latitude 34.764667 Caller’s latitude, if sent. (unit: degree) (+: North latitude, –: South latitude)
Longitude 135.375333
Caller’s longitude, if sent. (unit: degree) (+: East longitude, –: West longitude)
Altitude 30.5 Caller’s altitude, if sent. (unit: m) Records to one decimal place.
SSID -A Caller’s SSID, if sent. (0, -1 to -15, -A to -Z)
D-PRS Symbol Car Icon: Converts to text, None: Code
Course 123 Caller’s course (unit: degree)
Speed 23.5 Caller’s speed (unit: km/h) Records to one decimal place.
Power
49
TX power (unit: W)
Height
24
Antenna height (unit: m)
Gain
6
Antenna gain (unit: dB)
Directivity
Omni
Antenna directivity
(Omni, 45, 90, 135, 180, 225, 270, 315 or 360)
Object/Item
Name
HAM FES
Object name or Item name (up to 9 characters)
Data Type
Live Object
Data type of Object or Item (Live or Kill)
Temperature
20.5
Temperature (unit: ç) Records to two decimal places.
Rainfall
253.75
Rainfall (unit: mm) Records to two decimal places.
Rainfall (24
Hours)
253.75
Rainfall (24 Hours) (unit: mm) Records to two decimal places.
Rainfall
(Midnight)
253.75
Rainfall (Midnight) (unit: mm) Records to two decimal places.
Wind Direction
315
Wind Direction (unit: degree)
Wind Speed
10.0
Wind Speed (unit: m/s) Records to one decimal place.
Gust Speed
10.0
Gust Speed (unit: m/s) Records to one decimal place.
Barometric
1013.0
Barometric (unit: hPa) Records to one decimal place.
Humidity
85
Humidity (unit: %)
GPS Time Stamp
12:00:00 Time data that the caller station acquires the position data
GPS Message
Osaka City/
ID-4100
Caller is “NMEA”: Records the GPS message
Caller is “D-PRS: Records the D-PRS comment
QSO/RX Log items (Continued)
