D Command table
Cmd.
Sub
cmd.
Data Description
00 see p. 10-21 Send operating frequency for
transceive
01 see p. 10-21 Send operating mode for transceive
03 see p. 10-21 Read operating frequency
04 see p. 10-21 Read operating mode
05 see p. 10-21 Send operating frequency
06 see p. 10-21 Send operating mode
07 Select VFO mode
0C see p. 10-21 Read frequency offset*
1
0D see p. 10-21 Send frequency offset
0F Read duplex setting
(10=simplex, 11=DUP–, 12=DUP+)
10 Set simplex operation
11 Set DUP– operation
12 Set DUP+ operation
14 01 0000 to
0255
Send/read audio output level
( 000=Minimum, 0128=Center,
0255=Maximum)
03 0000 to
0255
Send/read squelch level
( 000=Minimum, 0128=Center,
0255=Maximum)
0A see p. 10-21 Send/read RF power setting
0B see p. 10-21 Send/read external microphone gain.
16 see p. 10-22 Send/read VOX gain.
15 01 00 Read noise/S-meter squelch status
(squelch close)
01 Read noise/S-meter squelch status
(squelch open)
02 0000 to
0255
Read S-meter level
(0000=S0, 0170=S9)
05 00 Read tone squelch and RF squelch
status (squelch close)
01 Read tone squelch and RF squelch
status (squelch open)
11 0000 to
0255
Read RF power meter
(0026=LOW, 0077=MID, 0255=HIGH)
16 42 00 Send/read Repeater tone OFF
01 Send/read Repeater tone ON
43 00 Send/read Tone squelch OFF
01 Send/read Tone squelch ON
02 Send/read Reversed Tone squelch ON
46 00 Send/read VOX function OFF
01 Send/read VOX function ON
4B 00 Send/read DTCS OFF
01 Send/read DTCS ON
02 Send/read Reversed DTCS ON
5B 00 Send/read DSQL/CSQL OFF (DV
mode only)
01 Send/read DSQL ON (DV mode only)
02 Send/read CSQL ON (DV mode only)
5C 00, 01, 02 Send/read GPS TX mode
(00=OFF, 01=D-PRS, 02=NMEA)
5D 00 to 09 Tone setting
00=OFF, 01=TONE, 02=TSQL,
03=DTCS, 04=TSQL-R, 05=DTCS-R,
06=DTCS (T), 07=TONE (T) /DTCS
(R), 08=DTCS (T)/TSQL (R), 09=TONE
(T) /TSQL (R)
Cmd.
Sub
cmd.
Data Description
18 00 Turning OFF the transceiver
01 Turning ON the transceiver*
2
19 00 Read transceiver ID
1B 00 see p. 10-22 Send/read Repeater tone frequency
01 see p. 10-22 Send/read Tone squelch frequency
02 see p. 10-22 Send/read DTCS code and polarity
07 see p. 10-22 Send/read CSQL code (DV mode)
1C 00 00 Send/read Transceiver’s status (RX)
01 Send/read Transceiver’s status (TX)
1F 00 see p. 10-22 Send/read DV MY call sign
01 see p. 10-22 Send/read DV TX call signs
02 see p. 10-22 Send/read DV TX message
20 00 00 00*
3
Send/read Auto DV RX Call signs
output OFF
01*
3
Send/read Auto DV RX Call signs
output ON
01 see p. 10-23 Output DV RX Call signs for transceive
02 see p. 10-23 Read DV RX Call signs for transceive
01 00 00*
3
Send/read Auto DV RX message
output OFF
01*
3
Send/read Auto DV RX message
output ON
01 see p. 10-23 Output DV RX message for transceive
02 see p. 10-23 Read DV RX message for transceive
02 00 00*
3
Send/read Auto DV RX status output
OFF
01*
3
Send/read Auto DV RX status output
ON
01 see p. 10-23 Output DV RX status for transceive
02 see p. 10-23 Read DV RX status for transceive
03 00 00 Send/read Auto DV RX GPS/D-PRS
data output OFF
01 Send/read Auto DV RX GPS/D-PRS
data output ON
01 see p. 10-24 Output DV RX GPS/D-PRS data for
transceive
02 see p. 10-24 Read DV RX GPS/D-PRS data for
transceive
04 00 00 Send/read Auto DV RX GPS/D-PRS
message output OFF
01 Send/read Auto DV RX GPS/D-PRS
message output ON
01 see p. 10-26 Output DV RX GPS/D-PRS message
for transceive
02 see p. 10-26 Read DV RX GPS/D-PRS message for
transceive
