Icom ID-4100A

10
OTHER FUNCTIONS
10-10
D Selecting the DTMF transmit speed
You can select the DTMF transmit speed.
DTMF > DTMF Speed
1.
Push [MENU].
2. Rotate [DIAL] to select “DTMF,” then push [ï].
3. Select “DTMF Speed,” then push [ï].
4. Select a transmit speed.
• 100ms: Transmits the DTMF tones at about 100
milliseconds per code.
5 characters per second.
• 200ms: Transmits the DTMF tones at about 200
milliseconds per code.
2.5 characters per second.
• 300ms: Transmits the DTMF tones at about 300
milliseconds per code.
1.6 characters per second.
• 500ms: Transmits the DTMF tones at about 500
milliseconds per code.
1 character per second.
5. Push [MENU].
• Returns to the standby screen.
When “100ms” is set,
the DTMF transmit
speed is fast.
When “500ms” is set,
the DTMF transmit
speed is slow.
Pi−, Po−, Pa−
Pi, Po, Pa
Image of the DTMF transmit speed
Using the DTMF memory (Continued)
