Cygnus 2 Operating Manual
Operate Display Description
1Rate
2 Thickness
3 Power Level
4 State of Material
5 State Timer
6 Material Timer
7 Material Being Deposited
8 Source Number In Use
9 Sensor Number In Use
10 Crystal Position In Use
11 Graphical Display of Rate Deviation or Power
12 Date and Time
13 Message Area
14 Function Key Definitions
15 Crucible Position
16 State preceding Stop
During the OPERATE display, the function keys below the screen function as
explained in Table 3-1.
Table 3-1 Operate display function keys
Key Function Description
F1 ZERO
THICKNESS
Pressing F1 resets the displayed thickness of the current
Material to zero.
F2 TOGGLE
MANUAL
Press F2 to put the Material in manual control so that the
power level is controlled by the Handheld Controller
(section 3.5.5). When in Manual, press F2 again to remove
the Material from the Manual state and place it into the
DEPOSIT state.
F3 SHOW ALL
MATERIALS/
SHOW GRAPH
Press F3 to toggle between showing all Materials (if more
are running) or showing only one Material.
