Ultrasonics and Machine Control Printed Circuit Boards
11-12 CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual
5. Connect the cable assemblies to the ultrasonics PCB (Refer to the following
table and Figure 11-3).
Table 11-3.
Cable connections on the
ultrasonics PCB
6. Replace the rear cover.
Now you must replace the Machine Control PCB, which resides in the control
panel assembly.
Loc. Connector Wire Color
J5 2-pin green, white
J7 12-pin black
J10 small 2-pin brown, orange
J13 large 2-pin orange, brown
J14 6-pin red, black, red, black, red, black
J18 2-pin black, black (twisted)
J17 4-pin (marked IRR) red, black, orange, violet
J16 4-pin (marked COOL) red, black, yellow, gray
J15 4-pin red, black, orange, brown
J11 small 2-pin red, black
J8 large 2-pin red, black
J3 5-pin violet, yellow
J1 10-pin yellow, brown, violet, blue, orange, red,
black
J9 20-pin ribbon cable
J12 40-pin ribbon cable
