Intel® Server Board S1200BT Service Guide 105
Table 10. POST Error Beep Codes
In the case of POST error(s) that are listed as Major, the BIOS enters the error manager
and waits for the user to press an appropriate key before booting the operating system or
entering the BIOS Setup.
The user can override this option by setting the POST Error Pause option as disabled on
the BIOS setup Main screen. If this option is disabled, the system boots the operating
system without user intervention. The default is disabled.
Beeps Error Message
POST Progress
Code
Description
3 Memory error Multiple System halted because a fatal error related to the
memory was detected.
The following Beep Codes are from the BMC, and are controlled by the Firmware team. They are listed here for
convenience.
1-5-2-1 CPU socket
population error
N/A CPU1 socket is empty.
1-5-2-4 MSID Mismatch N/A MSID mismatch occurs if a processor is installed
into a system board that has incompatible power
capabilities.
1-5-4-2 Power fault N/A DC power unexpectedly lost (power good dropout)
- Power unit sensors report power unit failure offset
1-5-4-4 Power control fault N/A Power good assertion timeout - Power unit sensors
report soft power control failure offset

Intel S1200BT Specifications

General

Chipset	Intel C204
Socket	LGA 1155
Form Factor	ATX
Memory Type	DDR3
Max Memory	32 GB
Memory Slots	4
PCIe x16 Slots	1
PCIe x4 Slots	1
PCI Slots	2
SATA Ports	6
Ethernet Ports	2
PCIe x8 Slots	1
Network	Intel 82574L
RAID Support	0, 1, 5, 10
