Intel® Server Board S1200BT Service Guide 9
Figure 4. Intel
®
Server Board S1200BTS Layout
A. Slot 4, 32 Mbit/33 MHz PCI N. SYS FAN 1
B. Slot 5/6, PCI Express* Gen2 x4 (x8
connector)
O. CPU connector
C. SATA_KEY P. CPU Fan connector
D. Slot 7, PCI Express* Gen2 x8 (x16
connector)
Q. Chassis Intrusion
E. Ethernet and Dual USB COMBO R. SATA_SGPIO
F. Ethernet and Dual USB COMBO S. SYS_FAN_3
G. Video port T. Six 3Gb/s SATA ports
H. External Serial port U. Low profile USB connector
I. CPU Power connector V. Internal USB
J. SYS_FAN_2 W. CMOS battery
K. DIMM slots X. Front Panel
L. MAIN power connector Y. HDD LED
M. TPM connector
