Intel® Server Board S1200BT Service Guide 13
Table 3. NIC LED Descriptions
RAID Support
Both the Intel
®
Server Board S1200BTL and S1200BTS provide two embedded
SATA controllers:
• Intel
®
Embedded Server RAID Technology II
• Intel
®
Rapid Storage RAID technology
The Intel
®
Embedded Server RAID Technology II provides RAID modes 0,1, 10, and 5
(with SW RAID key). The Intel
®
Rapid Storage RAID technology provides RAID modes
0, 1, 10, and 5.
The Intel
®
Server Board S1200BTL provides two 6Gb/s SATA ports and four 3Gb/s
SATA ports.
The Intel
®
Server Board S1200BTS provides six 3Gb/s SATA ports.
For information on how to configure RAID, refer to the RAID Software User’s Guide at:
http://www.intel.com/support/motherboards/server.
Hardware Requirements
To avoid integration difficulties and possible board damage, your system must meet the
following requirements outlined. For a list of qualified components, see the links under
“Additional Information and Software”.
Processor
The Intel
®
Server Board S1200BT supports the Intel
®
Xeon
®
E3-1200 Processors or the
2
nd
Generation Intel
®
Core™ i3 Processors in FC-LGA 1155 socket package with 5GT/s
point-to-point DMI interface to PCH and LGA 1155 pin socket.
LED Color Condition Description
LAN 1-2 Green On LAN link/no access
Green Blink LAN access
Off Idle
