Intel® Server Board S1200BT Service Guide 3
Table 2 summarizes the features of the server board.
Table 2. Server Board Features
Feature Description of S1200BTL Description of S1200BTS
Processors Supports for one Intel
®
Xeon
®
E3-
1200Processors or the 2
nd
Generation Intel
®
Core™ i3 Processors in FC-LGA 1155 socket
package.
• 5 GT/s point-to-point DMI interface to
PCH
• LGA 1155 pin socket
Supports for Intel
®
Xeon
®
E3-1200 V2
processors or the 3
rd
Generation Intel
®
Core™ i3 processors in FC-LGA 1155 socket
package.
• 5 GT/s point-to-point DMI interface to
PCH
• LGA 1155 pin socket
Supports for one Intel
®
Xeon
®
E3-1200
Processors or the 2
nd
Generation Intel
®
Core™ i3 Processors in FC-LGA 1155
socket package.
• 5 GT/s point-to-point DMI interface to
PCH
• LGA 1155 pin socket
Supports for Intel
®
Xeon
®
E3-1200 V2
processors or the 3
rd
Generation Intel
®
Core™ i3 processors in FC-LGA 1155
socket package.
• 5 GT/s point-to-point DMI interface to
PCH
• LGA 1155 pin socket
Memory Two memory channels with support for 1066/
1333 MHz (with Intel
®
Xeon
®
E3-1200
Processors or the 2
nd
Generation Intel
®
Core™ i3 Processors) or 1333/1600 MHz
(with Intel
®
Xeon
®
E3-1200 V2 Processors or
the 3
rd
Generation Intel
®
Core™ i3
Processors) ECC Unbuffered (UDIMM) DDR3.
• Up to 2 UDIMMs per channel
• 32 GB max with x8 ECC UDIMM (2-Gb
DRAM)
• 64-bit wide channels
• DDR3 I/O Voltage of 1.5 V
Two memory channels with support for
1066/1333 MHz (with Intel
®
Xeon
®
E3-
1200 Processors or the 2
nd
Generation
Intel
®
Core™ i3 Processors) or 1333/
1600 MHz (with Intel
®
Xeon
®
E3-1200 V2
Processors or the 3
rd
Generation Intel
®
Core™ i3 Processors) ECC Unbuffered
(UDIMM) DDR3.
• Up to 2 UDIMMs per channel
• 32 GB max with x8 ECC UDIMM (2-
Gb DRAM)
• 64-bit wide channels
• DDR3 I/O Voltage of 1.5 V
Chipset
• Support for Intel
®
C204 Platform
Controller Hub (PCH) chipset
• ServerEngines* LLC Pilot III BMC
controller (Integrated BMC)
Support for Intel
®
C202 Platform
Controller Hub (PCH) chipset

Intel S1200BT Specifications

General

Chipset	Intel C204
Socket	LGA 1155
Form Factor	ATX
Memory Type	DDR3
Max Memory	32 GB
Memory Slots	4
PCIe x16 Slots	1
PCIe x4 Slots	1
PCI Slots	2
SATA Ports	6
Ethernet Ports	2
PCIe x8 Slots	1
Network	Intel 82574L
RAID Support	0, 1, 5, 10
