14 Intel® Server Board S1200BT Service Guide
Except for these two processors, the Intel
®
Server Board S1200BT also supports the
Intel
®
Xeon
®
E3-1200 V2 Processors or the 3
rd
Generation Intel
®
Core™ i3 Processors
in FC-LGA 1155 socket package with 5GT/s point-to-point DMI interface to PCH and
LGA 1155 pin socket. For a complete list of supported processors, see the links under
“Additional Information and Software”.
Memory
The Intel
®
Server Board S1200BT supports a DDR3-based ECC UDIMM memory
subsystem and up to two DIMM sockets per channel.
See the following figure for channel slot configuration. The minimal memory population
is one DIMM in memory slot DIMM_A1. For a complete list of supported memory, see
the links under “Additional Information and Software”
Table 4. Memory Configuration Table.
The Independent Channel Mode is the default Maximum Performance Mode preferred for
Intel
®
Xeon
®
Processor E3-1200 Series based platforms. All two channels may be
populated in any order and have no matching requirements. All channels must run at the
same interface frequency, but individual channels may run at different DIMM timings
(RAS latency, CAS latency, and so on).
Configuration DIMM_A1 DIMM_A2 DIMM_B1 DIMM_B2
1 DIMM Single
Channel
A1 only Single
Channel
1 DIMM Single
Channel
B1 only Single
Channel
2 DIMMs Single
Channel
A1 Single Channel A2 Single Channel
2 DIMMs Single
Channel
B1 Single Channel B2 Single Channel
2 DIMMs Dual
Channel
Symmetric
A1 Dual Channel
Symmetric
B1 Dual Channel
Symmetric
3 DIMMs Intel
®
Flex Memory
A1 Dual Channel
Symmetric
A2 Dual Channel
Symmetric
B1 Dual Channel
Symmetric
3 DIMMs Intel
®
Flex Memory
A1 Dual Channel
Symmetric
B1 Dual Channel
Symmetric
B2 Dual Channel
Symmetric
4 DIMMs Dual
Channel
Symmetric
A1 Dual Channel
Symmetric
A2 Dual Channel
Symmetric
B1 Dual Channel
Symmetric
B2 Dual Channel
Symmetric
