Intel® Server Board S1200BT Service Guide 5
On-board Hard
Drive
Support for six Serial ATA II hard drives
through six onboard SATA II connectors with
SW RAID 0, 1, 5, and 10.
• Up to four SAS hard drives through option
Intel
®
SAS Entry RAID Module card
• Two 6Gb/s SATA ports and four 3Gb/s
SATA ports
Support for six Serial ATA II hard drives
through six onboard SATA II connectors
with SW RAID 0, 1, 5, and 10.
Six 3Gb/s SATA ports
RAID Support
• Intel
®
Embedded Server RAID
Technology II through onboard SATA
connectors provides SATA RAID 0, 1, and
10 and optional RAID 5 support provided
by the Intel
®
RAID Activation Key
AXXRAKSW5
• Intel
®
Rapid Storage RAID through
onboard SATA connectors provides SATA
RAID 0, 1, 5, and 10
• One optional internal SAS module
connector which supports
AXXRMS2AF040, AXXRMS2LL040, and
AXX4SASMOD
• Intel
®
Embedded Server RAID
Technology II through onboard SATA
connectors provides SATA RAID 0, 1,
and 10 and optional RAID 5 support
provided by the Intel
®
RAID
Activation Key AXXRAKSW5
• Intel
®
Rapid Storage RAID through
onboard SATA connectors provides
SATA RAID 0, 1, 5, and 10
LAN One Gigabit Ethernet device 82574L connect
to PCI-E x1 interfaces on the PCH
One Gigabit Ethernet PHY 82579 connected
to PCH through PCI-E x 1 interface
One Gigabit Ethernet device 82574L
connect to PCI-E x 1 interfaces on
the PCH
One Gigabit Ethernet PHY 82579
connected to PCH through PCI-E x 1
interface
Server
Management
Onboard LLC Pilot III Controller (iBMC)
• Integrated Baseboard Management
Controller (Integrated BMC), IPMI 2.0
compliant
• Integrated 2D video controller on
PCI-E x 1
Optional Intel
®
Remote Management Module
4 (RMM4) lite and optional dedicated
NIC module
—
Security TPM module connector TPM module connector
Feature Description of S1200BTL Description of S1200BTS
