60 Intel® Server Board S1200BT Service Guide
Figure 35. Delete EFI Boot Option Screen
Boot Manager Screen (Tab)
The Boot Manager screen allows the user to view a list of devices available for booting,
and to select a boot device for immediately booting the system.
Note: This list is not in order according to the system Boot Option order. The “Internal EFI
Shell” will always be available, regardless of whether any other bootable devices
are available.
To access this screen from the Main screen or other top-level Tab screen, press the right or
left arrow keys to traverse the tabs at the top of the Setup screen until the Boot Manager
screen is selected.
Figure 36. Boot Manager Screen
Error Manager Screen (Tab)
The Error Manager screen displays any POST Error Codes encountered during BIOS
POST, along with an explanation of the meaning of the code.
This screen is the same for both Bromolow and Romley boards.
To access this screen from the Main screen or other top-level Tab screen, press the right or
left arrow keys to traverse the tabs at the top of the Setup screen until the Error Manager
screen is selected.

Intel S1200BT Specifications

General

Chipset	Intel C204
Socket	LGA 1155
Form Factor	ATX
Memory Type	DDR3
Max Memory	32 GB
Memory Slots	4
PCIe x16 Slots	1
PCIe x4 Slots	1
PCI Slots	2
SATA Ports	6
Ethernet Ports	2
PCIe x8 Slots	1
Network	Intel 82574L
RAID Support	0, 1, 5, 10
