4 Intel® Server Board S1200BT Service Guide
I/O External connections:
• DB-15 video connectors
• DB-9 serial Port A connector
• Four ports on two USB/LAN combo
connectors at rear of board
Internal connections:
• Two USB 2x5 pin headers, each
supporting two USB 2.0 ports
• One 2x5 Serial Port B headers
• One I/O Module Connector
• Two 6Gb/s SATA ports and four 3Gb/s
SATA ports
• One SAS mezzanine slot supports for
optional SAS module
• Smart Module connector
External connections:
• DB-15 video connectors
• DB-9 serial Port A connector
• Four ports on two USB/LAN combo
connectors at rear of board
Internal connections:
• Two USB 2x5 pin headers, each
supporting two USB 2.0 ports
• One 2x5 Serial Port B headers
• Six 3Gb/s SATA ports
Add-in PCI, PCI
Express* Cards
With Intel
®
Xeon
®
E3-1200 processors or the
2
nd
Generation Intel
®
Core™ i3 Processors:
• Slot1: One 5V PCI 32 bit/33 MHz
connector
• Slot3: One PCI Express* Gen2 x8 (x4
throughput) connector
• Slot4: One PCI Express* Gen2 x8 (x4
throughput) connector
• Slot5: One PCI Express* Gen2 x8 (x4
throughput) connector
• Slot6: One PCI Express* Gen2 x16 (x8
throughput) connector
With Intel
®
Xeon
®
E3-1200 V2 processors or
the 3
rd
Generation Intel
®
Core™ i3
Processors:
• Slot1: One 5V PCI 32 bit/33 MHz
connector
• Slot3: One PCI Express* Gen2 x8 (x4
throughput) Gen2 connector
• Slot4: One PCI Express* Gen3 x8 (x4
throughput) connector
• Slot5: One PCI Express* Gen3 x8 (x4
throughput) connector
With Intel
®
Xeon
®
E3-1200 processors or
the 2
nd
Generation Intel
®
Core™ i3
Processors:
• Slot4: One 5V PCI 32 bit/33 MHz
connector
• Slot5: One PCI Express* Gen2 x8 (x4
throughput) connector
• Slot6: One PCI Express* Gen2 x8 (x8
throughput) connector
• Slot7: One PCI Express* Gen2 x16
(x8 throughput) connector
With Intel
®
Xeon
®
E3-1200 V2 processors
or the 3
rd
Generation Intel
®
Core™ i3
Processors:
• Slot4: One 5V PCI 32 bit/33 MHz
connector
• Slot5: One PCI Express* Gen2 x8 (x4
throughput) connector
• Slot6: One PCI Express* Gen3 x8 (x8
throughput) connector
• Slot7: One PCI Express* Gen3 x16
(x8 throughput) connector
System Fan
Support
Five 4-pin fan headers supporting four system
fans and one processor
Four 4-pin fan headers supporting four
system fans and one processor
Video Onboard ServerEngines* LLC Pilot III BMC
Controller
Silicon Motion SM712GX04LF02-BA
Feature Description of S1200BTL Description of S1200BTS
