22 Intel® Server Board S1200BT Service Guide
• Information enclosed in square brackets ([ ]) in the tables identifies areas where the
user must type in text instead of selecting from a provided option.
• Whenever information is changed (except Date and Time), the systems requires a
save and reboot to take place in order for the changes to take effect. Alternatively,
pressing <ESC> discards the changes and resumes POST to continue to boot the
system according to the boot order set from the last boot.
Map of Screens and Functionality
There are a number of screens in the entire Setup collection. They are organized into
major categories. Each category has a hierarchy beginning with a top-level screen from
which lower-level screens may be selected. Each top-level screen appears as a tab,
arranged across the top of the Setup screen image of all top-level screens.
There are more categories than will fit across the top of the screen, so at any given time
there will be some categories which will not appear until the user has scrolled across the
tabs which are present.
The categories and the screens included in each category are listed below, with links to
each of the screens named.
Categories (Top Tabs) 2nd Level Screens 3rd Level Screens
Main Screen (Tab)
Advanced Screen (Tab)
ª Processor Configuration
ª Memory Configuration
ª Mass Storage Controller Configuration
ª Serial Port Configuration
ª USB Configuration
ª PCI Configuration
ª System Acoustic and Performance
Configuration
Security Screen (Tab)
Server Management Screen (Tab)
ª Console Redirection
ª System Information
ª[With BMC Only] BMC LAN Configuration
ª [Non-BMC Only] Hardware Monitor
ª[Non-BMC Only] Realtime Temperature
and Voltage Status

Intel S1200BT Specifications

General

Chipset	Intel C204
Socket	LGA 1155
Form Factor	ATX
Memory Type	DDR3
Max Memory	32 GB
Memory Slots	4
PCIe x16 Slots	1
PCIe x4 Slots	1
PCI Slots	2
SATA Ports	6
Ethernet Ports	2
PCIe x8 Slots	1
Network	Intel 82574L
RAID Support	0, 1, 5, 10
