Intel S2600CP Family User Manual

Appendix C: BMC Sensor Tables Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
180
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type Event/Readi
ng Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm Stand-
by
Processor 1 Thermal Margin
(P1 Therm Margin)
74h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 2 Thermal Margin
(P2 Therm Margin)
75h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 3 Thermal Margin
(P3 Therm Margin)
76h
Platform-
specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 4 Thermal Margin
(P4 Therm Margin)
77h
Platform-
specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 1 Thermal
Control %
(P1 Therm Ctrl %)
78h All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 2 Thermal
Control %
(P2 Therm Ctrl %)
79h All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 3 Thermal
Control %
(P3 Therm Ctrl %)
7Ah
Platform-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 4 Thermal
Control %
(P4 Therm Ctrl %)
7Bh
Platform-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 1 ERR2 Timeout
(P1 ERR2)
7Ch All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset A –
Processor 2 ERR2 Timeout
(P2 ERR2)
7Dh All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset A –
Processor 3 ERR2 Timeout
(P3 ERR2)
7Eh
Platform-
specific
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset A –

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
