Intel
®
Server Board S2600CP and Server System P4000CP TPS Appendix C: BMC Sensor Tables
Revision 1.1
Intel order number G26942-003
181
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
Processor 4 ERR2 Timeout
(P4 ERR2)
7Fh
Platform-
specific
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset A –
Catastrophic Error
(CATERR)
80h All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset M –
Processor1 MSID Mismatch
(P1 MSID Mismatch)
81h All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset M –
Processor Population Fault
(CPU Missing)
82h All
Processor
07h
Digital
Discrete
03h
01 – State Asserted Fatal
As
and
De
– Trig Offset M –
Processor 1 DTS Thermal
Margin
(P1 DTS Therm Mgn)
83h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 2 DTS Thermal
Margin
(P2 DTS Therm Mgn)
84h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 3 DTS Thermal
Margin
(P3 DTS Therm Mgn)
85h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 4 DTS Thermal
Margin
(P4 DTS Therm Mgn)
86h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor2 MSID Mismatch
(P2 MSID Mismatch)
87h All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As
and
De
– Trig Offset M –
Processor 1 VRD
Temperature
(P1 VRD Hot)
90h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset M –
Processor 2 VRD
Temperature
(P2 VRD Hot)
91h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset M –
