Intel S2600CP Family User Manual

Appendix C: BMC Sensor Tables Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
182
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type Event/Readi
ng Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm Stand-
by
Processor 3 VRD
Temperature
(P3 VRD Hot)
92h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset M –
Processor 4 VRD
Temperature
(P4 VRD Hot)
93h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset M –
Processor 1 Memory VRD
Hot 0-1
(P1 Mem01 VRD Hot)
94h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 1 Memory VRD
Hot 2-3
(P1 Mem23 VRD Hot)
95h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 2 Memory VRD
Hot 0-1
(P2 Mem01 VRD Hot)
96h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 2 Memory VRD
Hot 2-3
(P2 Mem23 VRD Hot)
97h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 3 Memory VRD
Hot 0-1
(P3 Mem01 VRD Hot)
98h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 3 Memory VRD
Hot 2-3
(P4 Mem23 VRD Hot)
99h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 4 Memory VRD
Hot 0-1
(P4 Mem01 VRD Hot)
9Ah All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 4 Memory VRD
Hot 2-3
(P4 Mem23 VRD Hot)
9Bh All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
