Intel S2600CP Family User Manual

Appendix C: BMC Sensor Tables Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
184
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type Event/Readi
ng Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm Stand-
by
Processor 4 DIMM Aggregate
Thermal Margin 1
(P4 DIMM Thrm Mrgn1)
B6h
Platform
Specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Processor 4 DIMM Aggregate
Thermal Margin 2
(P4 DIMM Thrm Mrgn2)
B7h
Platform
Specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Fan Tachometer Sensors
(Chassis specific
sensor names)
BAh–
BFh
Chassis
and
Platform
Specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc =
Degraded
c = Non-fatal
2
As
and
De
Analog R, T M -
Processor 1 DIMM
Thermal Trip
(P1 Mem Thrm Trip)
C0h All
Memory
0Ch
Digital
Discrete
03h
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M -
Processor 2 DIMM
Thermal Trip
(P2 Mem Thrm Trip)
C1h All
Memory
0Ch
Digital
Discrete
03h
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M -
Processor 3 DIMM
Thermal Trip
(P3 Mem Thrm Trip)
C2h All
Memory
0Ch
Digital
Discrete
03h
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M X
Processor 4 DIMM
Thermal Trip
(P4 Mem Thrm Trip)
C3h All
Memory
0Ch
Digital
Discrete
03h
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M X
Global Aggregate
Temperature Margin 1
(Agg Therm Mrgn 1)
C8h
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 2
(Agg Therm Mrgn 2)
C9h
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 3
(Agg Therm Mrgn 3)
CAh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 4
(Agg Therm Mrgn 4)
CBh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
