Intel S2600CP Family User Manual

Intel
®
Server Board S2600CP and Server System P4000CP TPS Appendix C: BMC Sensor Tables
Revision 1.1
Intel order number G26942-003
185
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type Event/Readi
ng Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm Stand-
by
Global Aggregate
Temperature Margin 5
(Agg Therm Mrgn 5)
CCh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 6
(Agg Therm Mrgn 6)
CDh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 7
(Agg Therm Mrgn 7)
CEh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 8
(Agg Therm Mrgn 8)
CFh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Baseboard +12V
(BB +12.0V)
D0h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +5V
(BB +5.0V)
D1h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +3.3V
(BB +3.3V)
D2h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +5V Stand-by
(BB +5.0V STBY)
D3h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard +3.3V Auxiliary
(BB +3.3V AUX)
D4h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard +1.05V
Processor1 Vccp
(BB +1.05Vccp P1)
D6h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.05V
Processor2 Vccp
(BB +1.05Vccp P2)
D7h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
