Server Board Overview Intel® Server Boards S3200SH/S3210SH TPS
6 Revision 1.8
Intel Order Number: E14960-009
o One 4-pin SATA RAID Key
o One 2-pin intrusion detection
BIOS
o EFI BIOS
Power Management
o Support for Power Management of all capable components
o ACPI-compliant motherboard and BIOS
o Sleep Switch and dual mode LED indicator
Manufacturing
o Surface mount technology. Single-sided assembly for LC/V board SKUs and
double-sided assembly for the LX board SKU
o Six-layer PCB
Form Factor
o ATX 2.0, 12-inches x 9.6-inches, 1U thermally optimized, and SSI TEB Rev 2.11
compatible.
Universal Serial Bus 2.0 (USB)
o Two external USB ports (located at the rear panel) with an additional internal
header providing two optional USB ports for front panel support
o Supports wake-up from ACPI sleeping states S1 and S4 (S3 is not supported)
o Supports legacy keyboard/mouse connections when using a PS/2-USB dongle
LPC (Low Pin Count) bus segment with one embedded device
o Super I/O controller (SMSC* SCH5027D) providing all PC-compatible I/O (floppy,
serial, keyboard, mouse, two serial com ports) and integrated hardware
monitoring.
SSI-compliant connectors for SSI interface support
Standard 24-pin SSI front panel, 2x12 main power connector, and 2x4 CPU power
connector
Fan Support
o Five general purpose 4-pin fan headers
One 4-pin processor fan header (active heat sink required)
Four 4-pin system fan headers (3-pin fans are compatible with all fan
headers. You should only use 4-pin fans with Sys Fan 1 and Sys Fan
2; Sys Fan 3 and Sys Fan 4 are connected to the PWM processor,
which is programmed to work with the 4-pin active heat sink fan.)
Diagnostic LEDs to display POST (Power-on Self-Test) code indicators during boot
Onboard SATA RAID
o Intel
®
Matrix Storage Technology supports software SATA RAID 0, 1, 10 and 5;
Microsoft Windows* driver support only.
The following figure shows the board layout of the LX board SKU. A letter (shown in Table 1)
identifies each connector and major component.
