119
D
EA30 Imager
The EA30 imager is a compact high-performance undecoded imager with high
motion tolerance that can be used with the ED40 decode board. This chapter
provides the following information:
• EA30 Imager Features
• EA30 + ED40 Views
• EA30 Reading Distances
• Operational Current
• EA30 + ED40 Inrush Currents
• Motion Tolerance
• Mechanical Dimension
• Imager Ribbon Cable Connecting to ED40
• Imager Connector Contact Assignment
Note: For detailed information on the EA30 imager, see the EA30 Imager
Integration Guide available from your Intermec OEM representative.
