Appendix D — EA30 Imager
120 ED40 Decode Board Integration Guide
EA30 Imager Features
• Highest motion tolerance on the market
• Reads colored bar codes
• Laser framing for easy aiming
EA30 + ED40 Views
Mounted EA30 on the ED40 Decode Board
Unmounted EA30 with the ED40 Decode Board
Note: For more information on motion tolerance see “Motion Tolerance”
on page 131
