Chapter 1 — Introducing the ED40 Decode Board
2 ED40 Decode Board Integration Guide
What is the ED40 Decode Board?
The ED40 decode board is a companion module for Intermec’s family of imager
engines. It is used to control the imager, capture images and decode 1D and 2D
bar codes. The ED40 decode board can be used with the following Intermec
imager engines:
• EA11
• EA20X
• EA21
• EA30
ED40 Views
ED40 Decode Board
The ED40 can be used as a one piece mounted design or a 2 piece unmounted
design as shown in the drawing below.
Imager connector Host connector
