Appendix D — EA30 Imager
ED40 Decode Board Integration Guide 123
Operational Current
This section provides the operational current for the ED40 demo board + EA30 @
25° C / 77° F. The maximum operating current increases as the operating
temperature increases.
The values provided in this section are only for the sensor and aimer current on
contact 10.
Note: Power for the illumination LEDs is supplied by current through contacts
20, 21, and 22 as shown in “Imager Connector Contact Assignment” on
page 139. The peak current for contacts 20, 21, and 22 depend on the
illumination level selected. For an idea of peak current see “” on page 132.
Operational Current—ED40 Decode Board + EA30 (contact 10)
Specification
RS-232 Interface USB Interface
3.3 V 5.0 V 3.3 V 5.0 V
Full operational
(power enable low, trigger low)
—Maximum (aimer always on) 300 mA 190 mA 320 mA 200 mA
Active Idle current
(power enable low, trigger high)
70 mA max 50 mA max 100 mA max 70 mA max
Hibernate current
(power enable low, trigger high, hibernate activated)
2.5 mA 1.2 mA N/A N/A
Note: For information on Hibernate mode, see “Hibernate Mode” on page 37.
