Intermec ED40 - EA20 X Imager

81
B
EA20X Imager
The EA20X is a compact high performance imager that can be used with the
ED40 decode board. This chapter provides the following information:
• EA20X Imager Features
• EA20X + ED40 Views
• Operational Current
• EA20X + ED40 Inrush Currents
• Mechanical Dimensions
• Imager Ribbon Cable Connecting to ED40
• Imager Connector Contact Assignment
Note: For detailed information on the EA20X imager, see the EA20X Imager
Integration Guide available from your Intermec OEM representative.
