Technical Specifications
ED40 Decode Board Technical Specifications
Physical Characteristics
Height 5.6 mm (0.22 in)
Width 34 mm (1.34 in)
Depth 19 mm (0.75 in)
Weight > 10 g (0.35 oz)
Interfaces
RS-232, USB 2.0 (Keyboard HID, Virtual COM, and UVC)
Performance Characteristics
Supported Symbologies All major 1-dimensional and 2-dimensional
symbologies including postal symbologies.
Image Capture Signature capture and document imaging (under
license).
Image Format Raw, JPEG, TIFFG4
Electrical Characteristics
Operating Voltage 3.0 V to 5.5 V
Operating Current Depends on the imager (see the appendix for your
imager).
Environmental Characteristics
operating temperature -20°C to 60°C / -4°F to 140°F
(except in continuous operation, see “Thermal
Considerations” on page 13.)
storage temperature -30°C to 70°C / -22°F to 158°F
relative humidity 0 to 95% non-condensing
shock 2000 Grms, 0.7 ms, half sinus, 3 axes
vibration 8 Grms, from 10Hz to 500Hz, 2 hour/axis, 3 axes
thermal shock 32 cycles of -40°C / 85°C (25°F / 185°F)
30 minutes @ each temperature
Transfer time: <5 seconds
Note: Operational current for the ED40 + imager depends on the imager used.
See the appendix for your imager for details.
