Chapter 1 — Introducing the ED40 Decode Board
ED40 Decode Board Integration Guide 3
Example of a Mounted Design and an Unmounted Design with an EA11 Imager
Handling Precautions
While working with the ED40, make sure that it is protected from dust and
humidity.
ED40 decode board
mounting bracket
EA11 imager
ED40 decode board
ribbon cable
EA11 imager
Mounted
Unmounted
Integrated circuits on the printed circuit board (PCB) are very sensitive to
damage by electrostatic discharge (ESD). Follow standard ESD guidelines
to avoid damaging the equipment you are servicing.
Because finger oils can impede the performance of scanner parts and
dissolve the reflective coating of the plastic mirrors, always wear finger cots
or non-powdered latex gloves when handling optical parts.
