Intermec PC43t User Manual

Chapter 5 — Troubleshoot the Printer
PC23 and PC43 Desktop Printer User Manual 107
Printing on regular media (not
RFID) is slow and halted in
between labels.
RFID is enabled. Disable RFID from the
web page or the Main Menu.
I am using an application to write
to RFID tags and the printer is
printing “VOID” labels.
Try these possible solutions:
• The printer may not recognize the
RFID media type. Restart the printer
or run the media or RFID calibration
wizard.
• You may need to modify the Tag
Position parameter.
• You may need to adjust the output
power (field strength) to the antenna.
I receive this message “No RFID
tag found.”
Try these possible solutions:
• Make sure you are using RFID media.
• You may need to modify the Tag
Position parameter.
• The tag may be broken. Try printing
on a different label.
When I send a TAGREAD or
TAGWRITE command, I get this
error message: “Tag format
error.”
The TAGFORMAT defined for the
operation determines the number of
required parameters. You may need to
modify the TAGFORMAT. For help, see
the
Intermec Fingerprint Command
Reference Manual or the IPL
Command Reference Manual. For more
information, see the EPC Tag Data
Standard (v1.1, revision 1.27) available
from the EPCglobal website at
www.epcglobalinc.org.
Problems and Possible Solutions (Continued)
Problem Possible Solution

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
