INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Product dimensions
-99-
Appendix A Product dimensions
A.1 LED keypad diagram
Digital
display area
Increase/
decrease
key
Program/exit
key
Short-cut multi-
function key
Run key
Function
indicator
Unit indicator
Confirmation
key
Right shift key
Stop/fault
reset key
Figure A-1 Keypad diagram
A.2 External keypad installation dimensions
Simple keypad bracket
(61006-00911)
57.1
82.0
Customer installation
dimensions
54.3
124.0
76.1
115.0
88.0
Figure A-2 External keypad
