INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-44-
Function
code
Name
Description
Default
Modify
obtained by the linear relationship between
the upper and lower limits and their
corresponding settings.
Present temperature = corresponding
percentage × 160℃
Setting range of P05.37: 0.00V–P05.39
Setting range of P05.38: -100.0%–100.0%
Setting range of P05.39: P05.37–10.00V
Setting range of P05.40: -100.0%–100.0%
P05.41
PT1 input filter time
0.000s–10.000s
0.300s
○
P05.47
PT2 lower limit
0.00V–P05.49
0.00V
○
P05.48
Corresponding setting
of PT2 lower limit
-100.0%–100.0%
12.5%
○
P05.49
PT2 upper limit
P05.47–10.00V
10.00V
○
P05.50
Corresponding setting
of PT2 upper limit
-100.0%–100.0%
75.0%
○
P05.51
PT2 input filter time
0.000s–10.000s
0.300s
○
P06 group Output terminals
Function
code
Name
Description
Default
Modify
P06.01
Y1 output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6–11: Reserved
12: Ready for running
13: Pre-exciting
14–19: Reserved
20: External fault is valid
21–22: Reserved
23: Modbus communication virtual terminal
output
24–26: Reserved
27: Fan start/stop control
0
○
P06.02
RO1 output
0
○
P06.03
Solenoid valve output
(TA1-TC1)
0
○
0
○
