INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-58-
Function
code
Name
Description
Default
Modify
sampling cycle, the slower the response
speed.
Setting range: 0.001–10.000s
P09.08
Final limit of PID
control deviation
It means the max. allowed deviation quantity
of the PID system feedback value relative to
closed-loop reference value. Within the
deviation limit, PID regulator stops
regulating, this parameter can be used to
regulate the precision and stability of PID
system.
Setting range: 0.0–100.0%
0.1%
○
P09.09
Upper limit value of
PID output
P09.10 (lower limit value of PID output)
–100.0%
100.0%
○
P09.10
Lower limit value of
PID output
-100.0%–P09.09 (upper limit value of PID
output)
0.0%
○
P09.11
Feedback offline
detection value
0.0–100.0%
0.0%
○
P09.12
Feedback offline
detection time
0.0–3600.0s
1.0s
○
P09.13
PID regulation
selection
0x00–0x11
LED ones:
0: Continue integral regulation when the
frequency reaches upper/lower limit
1: Stop integral regulation when the
frequency reaches upper/lower limit
LED tens:
0: The same with the set direction
1: Contrary to the set direction
0x01
○
P09.14
Differential filter times
0–60
2
○
P11 group Protection parameters
Function
code
Name
Description
Default
Modify
P11.00
Phase loss protection
0x0000–0x1111
LED ones:
0: Disable input phase loss software
protection
0x0110
○
