Goodrive300-01A-RT series integrated machine HMI
-137-
Appendix C HMI
C.1 Specifications
Table C-1 Touch screen specifications
Category
Function
Specifications
Hardware
parameter
Screen
7” 16: 9 TFT LCD screen
Resolution
800×480
Color
24 bits
Brightness
360 cd/m²
Backlight
LED
LCD lifetime
50000 hours
Touch screen
4-wire industrial resistance touch screen
CPU
600MHz ARM Cortex-A8
Memory
128M Flash + 128M DDR3
RTC
Real-time clock (embedded)
Ethernet
None
USB port
1 USB Slave 2.0 port; 1 USB Host 2.0 port
Program download
method
USB Slave/U disk
Serial
communication port
COM1: RS232/RS485/RS422；
COM2: RS485
COM3: RS232
Viewing angle of
LCD
(T/B/L/R)
50'/70'/70'/70'
Electrical
performance
Rated power
< 10W
Rated voltage
DC24V, allowable working range DC 9V–28V
Power supply
protection
Surge protection capability
Allowed power
outage
< 5ms
CE & RoHS
Compliant with EN61000-6-2:2005 and
EN61000-6-4:2007
Compliant with RoHS lightning surge ±1kV, group pulse
±2kV
Static contact 4kV, air discharge 8kV
Environment
requirement
Working
temperature
0–50℃
